抽屉式屏蔽箱
QT4630W
1、匹配自动半自动化使用
2、满足3C电子产品的屏蔽耦合测试,通用夹具
3、支持0.5-6G测试频段
4、支持多种屏蔽滤波接口定制
1、匹配自动半自动化使用
2、满足3C电子产品的屏蔽耦合测试,通用夹具
3、支持0.5-6G测试频段
4、支持多种屏蔽滤波接口定制
|
Product Name |
EMI automatic test telephone Mobile shielding box |
|
Model |
QT4530W |
|
Material |
Metal sheet |
|
Frequency |
0.8GHZ-6GHZ |
|
Isolation: |
2.4GHz≥80dB &5.8GHz≥70 dB |
|
Work Size(mm): |
(L) 370mm x (W) 320 MMX (H) 270mm |
|
Universal fixture Size(mm): |
(L)180mm*(W)150mm (up to 8 inches) |
|
Exterior Size (mm): |
(L) 460 x (W) 380x (H) 330mm |
|
Standard Intaface |
SMA*4;DC*1;USB*2;RS-232*1;RJ45*1 or as client request |
|
Color |
White and blue |
|
Net Weight |
35kg |
|
Package |
Wooden Package for EMI rf shield box test telephone Mobile shielding box enclosure |
